Plastic Bottle Recycling Production Line / Waste Plastic Recycling Machine

Brand Name : CMT

Model Number : customization

Certification : ISO

Place of Origin : China

MOQ : Negotiable

Price : Negotiable

Payment Terms : T/T, L/C

Supply Ability : 5000 sets/year

Delivery Time : 30 working days

Packaging Details : standard export package

material : plastic

turnkey project : yes

capacity : 200-2000kg/h

power : 296.2kw

Contact Now

Plastic Bottle Recycling Production Line/Waste Plastic Recycling Machine

1.Production area:

The whole production area: 100*20*5m
Factory requirement:
1.Water resource
2.Three phase power supply
3.3workers needed
Factory rated power consumption:296.2KW

Production procedure:
Step 1:Sorting table(& metal detector)
Step 2:Belt conveyer
Step 3:Label separate machine
Step 4:Belt conveyer
Step 5:Crusher
Step 6:Screw loader
Step 7:Steam washer
Step 8:Screw loader
Step 9:Friction washer
Step 10:Double screw rinsing machine
Step 11:Screw loader
Step 12:Double screw rinsing machine
Step 13:Screw loader
Step 14:Dewaterer
Step 15:Label air separator
Step 16:Drying system

2.Machine list

No.	Equipment name	Quantity
1	sorting table(& metal detector)	2
2	belt conveyer	2
3	lbel separate mchine	2
4	belt conveyer	2
5	crusher	2
6	scriw loader	2
7	steam washer	2
8	screw loader	2
9	friction washer	1

10	double screw rinsing machine	1
11	screw loader	1
12	double screw rinsing machine	1
13	screw loader	1
14	dewaterer	1
15	label air separator	1
16	drying system	1
17	electrical equipment	1
